steam locomotive washing

UP5521

Tidewater Western owner
Just how often does any steam locomotive needs to be washed clean in time for its next run? Then I also noticed the firebox had to be cleaned out as well and new fire brick had to be installed as well during its time in the shops while being maintained this also goes for 0-8-0 and 0-6-0 locomotives as well, switching railroad cars does put alot of wear on the locomotive's firebox and not to mention the drivers themselves which is no surpise because this is what the average railroader had to do when a locomotive had finished its first run,I bet cleaning out the firebox of any locomotive is filthy and dangerous :cool:

Over here (UK) this was mostly done after the days work had finished unless it's a special then (I presume) they were cleaned for the next run not too sure tho

:D

Andy

Steam loco washing.

Just how often does any steam locomotive needs to be washed clean in time for its next run? Then I also noticed the firebox had to be cleaned out as well and new fire brick had to be installed as well during its time in the shops while being maintained this also goes for 0-8-0 and 0-6-0 locomotives as well, switching railroad cars does put alot of wear on the locomotive's firebox and not to mention the drivers themselves which is no surpise because this is what the average railroader had to do when a locomotive had finished its first run,I bet cleaning out the firebox of any locomotive is filthy and dangerous :cool:
In the UK steam locos were not washed [with water] but cleaned with parrafin,usually when they were in the shed for boiler washing, or if working a special train[ ie A royal train}
The fire was cleaned when the loco.arrived on the shed after a run along with the ash from the smokebox.
On the LMS after so many runs{I believe about 7}The fire was fully removed from the firebox and the loco was allowed to cool down,. THE INSIDE of the boiler was then washed out, to clean any Impurities that had been in the water, using a high pressure hose. tThere were several washout plegs around the boiler to allow this and to ensure that the whole of the boiler was cleaned.At the same time IF the brick arch was in a poor condition it would be replaced, other wise it would be left in situ.
Yes, cleaning out fire boxes was a dirty job, but I would not describe it as dangerous.

Harry Failem

In the steam days of NSW, the loco's were very rarely washed and were always covered in a thick layer of road grime and crap. The black engines were given an coat of black oil after a routine tune up if they were lucky. Whilst not the cleanest engines, (by far) they certainly were reliable.

In the days of preservation (today) all steam locos are polished before and washed after every run. Alot of the old blokes say that they have never seen these locos so clean in 40 odd years! :D

I'm a voulenteer on the mid-hants preserved railway and we wash the locos before they go out in the morning.

Meyshollop

I am going off of Norfolk Western, but they tended to clean their locomotives quite regularly. They cleaned them with high pressure water, and some other chemical that I forget right now, and I am sure it wasn't paraffin.

Washing was pretty important because road grime could rot the metal, just like a car.

I tend to think back then that yes,NSW steam locomotives were not the cleanest locomotives which could cause complaints from passengers riding behind them but that is typical for steam locomotives and yes there are some diesel locomotives that are like that as well but I don't know if they can be classified as the neatest locomotives though!:cool:

yet I have to give the British railway workers credit for the excellent job they do in not just restoring the steam engines but cleaning them as well! Now I wonder if the scrapyard engines of the N&W could be cleaned up and maybe one day one could run again, I know the 475 is running at strasburg but there are resources and money that needs to be put in place before that can happen but I don't know!:o

I'm a voulenteer on the mid-hants preserved railway and we wash the locos before they go out in the morning.

Meyshollop

So am I, well, I was until about 2-3 weeks ago, I moved to website work afterwards, I am still working for the railway, but from home at the moment. I should be administrating the MHR Rangers. Oh well. Does Len manage you? Or do you get David (M) instead?

Locos, IIRC, the standard proceedure at the Watercress Line for cleaning was about 1/4 bucket full of parafin, then 2in of cylinder oil, mixed in, then cleaned with some rags and a couple of brushes to get in the small areas.

Smoke boxes are cleaned after every shift, as the loco comes off shed, the fire is also dropped at the same time and the locomotive cab floor washed at the same time.

Tubes are cleaned as and when needed (usually when the loco is out of traffic, I did that a while ago and you are often black when you come out of the smoke box, much to "Rob's" amusement.), boilers were washed once every approximately 6 months, but now Ropley has a reverse isomosis system, its increased greatly. (Basically, pure water.) Brick arches are replaced when needed, usually, when the loco is being examined, if there is damage, its usually reported. Boilers are inspected annually, as most of the other equipment and overhauled once every 10 years.

(sometimes, the boiler has an extension of a year, if it can do a year, then it is a steaming countdown, usually 20 at the highest, but cannot be used afterwards, unless it has been certified and overhauled.)

That MidHants bunch look a bit mean. :hehe:



Someones been in the smokebox I see. ;)

Were not mean, i'm not in that pic, we generally keep to ourselves (well that's what iv'e found )

WEN: I get david M


Many thanks

Meyshollop

Last edited:
That MidHants bunch look a bit mean. :hehe:



Someones been in the smokebox I see. ;)
Ahh yes, some rangers, Nick Clark, Tom Homewood (Zoid99 on the forums - with the grease top), Andy Christie (I think its spelt right), Alistar Christie and I think its yong Nick Tippen at the front.
Tom and Nick are both over 16 now, so they are rostered for loco work.

This is me (before the long hair):

Another person you may want to talk to, is Karl (Klambert), he's even met me in RL, we were both discussing sims and it was like "I deal with Sims", "So do I, I model for one" and I just got the hint straight away, "So, not Trainz is it?", "Yeah... how do you know?", "I'm Wessex!", "Not Wessex_Electric_Nutter", "Yep, thats the one!"

Oh god! I need to get up there on a Saturday, my PTS expires this month!
Anyway, I'm suppose to be manging the Rangers, but Bob A and Len agreed that I am better off in administration. However, I had a little small problem within the group I was tied to, nothing to do with the boss (Roger), but I encountered a small outburst from someone a while ago, but I also have other duties to do now, so I've seperated myself and I may have a job with Southern as I got invited for an assessment.

If your going to go on a saturday, i suggest going on the 12th ( second day of the big steam gala, should be good )

I'm in school on the friday so i can only go on the saturday, should be quite an early start considering the amount of loco's in steam, that means plenty of cleaning and other jobs for me and the other rangers:):):):)


Meyshollop

Last edited:
clean to mucky...

Most of us will arrive clean and leave with soot and grime all over our faces and overalls...

BLACKWATCH, thats a very old photo.

Meyshollop

Most of us will arrive clean and leave with soot and grime all over our faces and overalls...

BLACKWATCH, thats a very old photo.

Meyshollop


Clean? You still have the crap left from weeks previously, look at my orange jacket, still stained from the cylinder oil given. BTW, ever wondered how to grease the axle boxes? Go and get a oil can, remove the cork and look in. The 08s have dipsticks, which is even better!

My gloves went black within 3 days of being at MHR. My high vis is more like a low vis from the amount of grime.
